    Nickel Alloy Clad Plate for Heaters Explosion Clad N04400 Monel400

    Ask Lasest Price
    Brand Name : Suntech or OEM
    Model Number : E0042
    Certification : EN10204 3.1, EN10204 3.2, DNV, TUV, SGS, etc
    Price : negotiation
    Payment Terms : L/C, D/A, T/T, D/P
    Supply Ability : 35000tons/Year
    Delivery Time : 60 working days after received your payment
    • Product Details
    • Company Profile

    Nickel Alloy Clad Plate for Heaters Explosion Clad N04400 Monel400

    Explosion Clad N04400 (Monel400)/SA516 Gr.60 Nickel Alloy Clad Plate for Heaters


    Quick Product Details:


    Cladding metal:N04400 (Monel400)

    Base metal:SA516 Gr.60

    Size:(3+20)*1500*3000mm

    Production code:ASTM B265, ASME SB265

    Edge Treatment:Waterjet Cutting

    Surface status: Auto polished

    Packing: Seaworthy packing


    Table for available type of Nickel alloy clad plates:


    Product Names:

    Nickel & Nickel Alloy Clad Plate/Sheet, Nickel & Nickel Alloy Clad Plate/ Tube Plate

    Production Codes:

    ASTM B265, ASME SB265, DIN , BS, JIS, GB/T, ISO, etc.

    Nickel Grades:

    ASME B127, ASME B162, ASME A164 UNS N02200 (Ni200), N04400 (Monel 400), N06600 (Inconel 600), N08800 (Incoloy 800), N08825 (Incoloy 825), N10276 (C276), N10675 (B-3), N06022 (C22), N06059 (C59), N06200 (C2000), N08020 (20 Alloy)

    Form

    Description

    Base Layer

    Base Layer Grade

    Maximum Size

    Clad Plate

    Nickel / Carbon Steel Clad

    Carbon steel plate and forging

    SA516 Gr.60(N),Gr.70(N),SA387 Gr.11, Gr.22, SA266, SA350, etc.

    (1.5~14)/(2~200) x W(max W 4110) x L(max L 7000)

    Nickel / Copper (Naval Brass) Clad

    Copper, Naval Brass

    C10100, C10200, C11000, C26200, C28000, C46400, C70600, C71500, etc.

    (1.5~14)/(2~100) x W(max W 2100) x L(max L 6000)

    Nickel / Aluminum Clad

    Aluminum

    A1050, A1060, A1070, A1100, A5052, etc.

    (1.5~14)/(2~50) x W(max W 1500) x L (max L 4000)

    Titanium / Nickel Clad

    Nickel and its alloy

    N02200, Monel 400, Inconel 600, Incoloy 800, 825, C276, C22, etc

    (1.5~14)/(2~50) x W(max W 2000) x L (max L 5000)

    Nickel / Carbon Steel / Nickel Clad

    Carbon steel plate and forging

    SA516 Gr.60(N),Gr.70(N),SA387 Gr.11, Gr.22, SA266, SA350, etc.

    (1.5~14)/(6~200)/(2~10) x W(max W 3000) x L(max L 6000)

    Nickel / Copper / Nickel Clad

    Copper, Naval Brass

    C10100, C10200, C11000, C26200, C28000, C46400, C70600, C71500, etc.

    (1.5~14)/(6~100) x W(max W 2100) x L(max L 6000)

    Nickel / Carbon Steel / Stainless Steel Clad

    Carbon steel plate and forging

    SA516 Gr.60(N),Gr.70(N),SA387 Gr.11, Gr.22, SA266, SA350, etc.

    (1.5~14)/(6~200)/(1.5~10) x W(max W 4110) x L(max L 7000)

    Duplex, Stainless Steel & their forgings

    304L,316L, 316Ti, 321, 317L, 310S, 410S, 904L, 1805, 2205, 2507, Al6XN, 254sMo,etc.

    Aluminum / Nickel / Carbon Steel Clad

    Aluminum

    A1050, A1060, A1070, A1100, A5052, etc.

    (1.5~40)/(1-5)/(6~200) x W(max W 1000) x L(max L 1000)

    Carbon steel plate and forging

    SA516 Gr.60(N),Gr.70(N),SA387 Gr.11, Gr.22, SA266, SA350, etc.

    Aluminum / Nickel / Copper Clad

    Aluminum

    A1050, A1060, A1070, A1100, A5052, etc.

    (1-10)/(1-5)/(6-100) x W(max W 1000) x L(max L 1000)

    Copper, Naval Brass

    C10100, C10200, C11000, C26200, C28000, C46400, C70600, C71500, etc.

    Application: Petro-chemical, Vacuum Salt Industry, Chlor-alkali, Metallurgical, Food, Light Industry, Medicine, Auto Industry, Electrolytic Aluminum, Fertilizer, Kitchenware, Power Industry, Building Materials, Electrolysis Industry, Hydrometallurgy etc.


    Applications:
    Petro-chemical, Vacuum Salt Industry, Chlor-alkali, Metallurgical, Food, Light Industry, Medicine, Auto Industry, Electrolytic Aluminum, Fertilizer, Power Industry, Building Materials, Electrolysis Industry, Hydrometallurgy etc.
